 introduction

Appearance:


appearance

Application:


  1. It is applicable to playground lighting ,stadium lighting,plaza lighting, and so on.
  2. New Installation or Replace the traditional High Pressure Sodium Lamp, High Pressure Mercury Lamp, and Metal Halide Street Lamps. Etc.

Features:


  • Adoption LEYOND exclusive Lens with light transmittance up to 98%.
  • Perfect Light Distribution Solution:Adoption of integrated shell optic lens, enhance the brightness and illumination uniformity.
  • There are 25°, 60°, 90°, beam angle options for the Lens.
  • Scientifically-designed heat dissipater with much better cooling effect.
  • High luminous efficiency, Whole lamp output light effiency >150LM/W.
  • High quality power supply, input voltage 100-240V. The power efficiency is more than 90%, power factor greater than 0.98, UL compulsory certification.
  • For the traditional light source such as the High Pressure Sodium, if the voltage fluctuation ±7%, the brightness and lifetime will be reduced very fast, but for LEYOND LED, even the voltage fluctuation is ±20%, the brightness and lifetime will not be influenced at all;Over Current, Over Voltage, Over Heat, Thunder Protection.
  • Impact Resistance, Shock-proof, Without Ultraviolet (UV) and Infrared (IR) Radiation: No filament and glass frames, avoid break of the traditional lamp,without harm to the human body.
  • The CCT of Warm white、Neutral white、Pure white to meet the needs of different occasions, eliminated the low color temperature of the sodium lamp which cause the depressed mood, observers will feel more comfortable.
General Information
Product Model LY-ST23100PW / LY-ST23100NW / LY-ST23100WW
Product Information
Power 100
Luminous Flux(lm) 16000 / 14800 / 13500
Luminous Efficiency(lm/w) >160
Chip Brand LUXEON 5050/LEYOND 5050
CRI (Color Rendering Index) >75
Beam Angle 25°,60°, 90°
Color Temperature Pure white:5000-6500K Warm white:2700-3200K Neutral white:4000-4500K
Lifespan(hrs) >50000
IP Rating IP65
Net Weight(kg) 3.5
Size(mm) 320X222X76
LED Driver XLG-100-48A
Dimmable YES&NO
Package Details
Package Size(mm) 326X390X135
Package Quantity(Pcs) 1
Gross Weight(kg) 4.1
